Description
280C Compressor
Air and Pneumatic Delivery Systems 12V Compressors parts by OBA
The VIAIR 280C Dual Performance Value Pack is ideal for air suspension systems capable of providing a maximum of 150 PSI and a 30% duty cycle. The kit features two 12-volt Silver on Black 280C air compressors, two 40-amp relays and a 110 PSI cut-on, 145 PSI cut-off heavy-duty pressure switch. Each 280C Dual Performance Value Pack also comes with remote mountable air filter assemblies and mounting hardware.
| FEATURES |
| – Check Valve |
| – Vibration Isolators |
| – Mounting Hardware |
| – Stainless Steel Braided Leader Hose |
| – Direct Air Filter Assembly |
| – (2) Replacement Air Filter Elements |
| – Installation Instructions |
| – |
| – |
| SPECIFICATIONS |
| – 12-Volt |
| – Permanent Magnetic Motor |
| – Duty Cycle: 30% @ 100 PSI |
| – Max. Working Pressure: 150 PSI |
| – Max. Air Tank Size: 2.5 Gallon |
| – Max. 12V Amp Draw: 19 Amps |
| – Ingress Protection Rating: IP54 |
| – Dimensions: 7.8″L x 3.95″W x 6.35″H |
| – Net Weight: 6.95 lbs. |
* For 12V Only.
Please Note: Use thread sealant for proper installation. Thread tape is not recommended.
Properly sealed, recommended torque for 1/8″ is 10 ~ 11 ft. lbs. Recommended torque for 1/4″ and 3/8″ is 16 ~ 18 ft. lbs.
PERFORMANCE DATA
| PSI |
CFM |
A |
BAR |
LPM |
A |
| 0 |
1.59 |
10 |
0 |
45.0 |
10 |
| 10 |
1.49 |
12 |
1.0 |
40.2 |
13 |
| 20 |
1.33 |
13 |
2.0 |
32.1 |
14 |
| 30 |
1.11 |
14 |
3.0 |
29.0 |
15 |
| 40 |
1.04 |
15 |
4.0 |
26.4 |
16 |
| 50 |
0.99 |
15 |
5.0 |
24.2 |
16 |
| 60 |
0.92 |
16 |
6.0 |
22.0 |
17 |
| 70 |
0.87 |
16 |
7.0 |
21.0 |
19 |
| 80 |
0.81 |
17 |
8.0 |
19.4 |
18 |
| 90 |
0.76 |
17 |
9.0 |
17.5 |
17 |
| 100 |
0.74 |
19 |
10.0 |
15.3 |
17 |
| 110 |
0.71 |
19 |
|
|
|
| 120 |
0.67 |
18 |
|
|
|
| 130 |
0.62 |
17 |
|
|
|
| 140 |
0.57 |
17 |
|
|
|
| 150 |
0.51 |
17 |
|
|
|
FILL RATES
| 1.0 GALLON TANK |
FILL RATE |
| 0 to 105 PSI |
1 min. 10 sec. (± 05 sec.) |
| 85 to 105 PSI |
20 sec. (± 03 sec.) |
| 0 to 145 PSI |
1 min. 40 sec. (± 05 sec.) |
| 110 to 145 PSI |
35 sec. (± 03 sec.) |
| 2.5 GALLON TANK |
FILL RATE |
| 0 to 105 PSI |
2 min. 35 sec. (± 10 sec.) |
| 85 to 105 PSI |
44 sec. (± 05 sec.) |
| 0 to 145 PSI |
4 min. 30 sec. (± 10 sec.) |
| 110 to 145 PSI |
1 min. 36 sec. (± 05 sec.) |
* Supply Voltage: 13.8 Volts
OE Reference: 28002
SKU: 510010001
280C Compressor
£195.85inc 20% VAT
280C Compressor
OE Code : 28002
Application : Car and Truck, Off Road and 4x4, RV and Motorhome
Fitment / Details : 12V Model, Compressors (Singles), Max Working Pressure 150PSI
Colour : Pewter
Description
280C Compressor
Air and Pneumatic Delivery Systems 12V Compressors parts by OBA
The VIAIR 280C Dual Performance Value Pack is ideal for air suspension systems capable of providing a maximum of 150 PSI and a 30% duty cycle. The kit features two 12-volt Silver on Black 280C air compressors, two 40-amp relays and a 110 PSI cut-on, 145 PSI cut-off heavy-duty pressure switch. Each 280C Dual Performance Value Pack also comes with remote mountable air filter assemblies and mounting hardware.
* For 12V Only.
Please Note: Use thread sealant for proper installation. Thread tape is not recommended.
Properly sealed, recommended torque for 1/8″ is 10 ~ 11 ft. lbs. Recommended torque for 1/4″ and 3/8″ is 16 ~ 18 ft. lbs.
PERFORMANCE DATA
FILL RATES
* Supply Voltage: 13.8 Volts
OE Reference: 28002
SKU: 510010001
Additional information
28002
Car and Truck, Off Road and 4×4, RV and Motorhome
12V Model, Compressors (Singles), Max Working Pressure 150PSI
Pewter
